Consulte disponibilidad en la sucursal más cercana
-1/2.8″ 2Megapixel STARVIS™ CMOS.
-Zoom óptico de 32x.
-Tecnología Starlight.
-Máximo de 25/30fps@1080P.
-Distancia IR de hasta 150 m.
-Auto-tracking 3.0.
-Protección perimetral.
-Detección facial.
-SMD 4.0.
-Selección rápida.
-Protección IP67, IK10.
$611395
Precio (IVA Incluído)
El precio puede estar sujeto a cambios,
confirme con nuestros asesores de ventas.
Consulte disponibilidad en la sucursal más cercana
Descripción Corta
-1/2.8″ 2Megapixel STARVIS™ CMOS.
-Zoom óptico de 32x.
-Tecnología Starlight.
-Máximo de 25/30fps@1080P.
-Distancia IR de hasta 150 m.
-Auto-tracking 3.0.
-Protección perimetral.
-Detección facial.
-SMD 4.0.
-Selección rápida.
-Protección IP67, IK10.
Características
| Camera | ||||
| Image Sensor | 1/2.8″ CMOS | |||
| Pixel | 2 MP | |||
| Max. Resolution | 1920 (H) × 1080 (V) | |||
| ROM | 4 GB | |||
| RAM | 1 GB | |||
| Electronic Shutter Speed | 1/1 s–1/30,000 s | |||
| Scanning System | Progressive | |||
| Min. Illumination | Color: 0.005 lux@F1.3 B/W: 0.0005 lux@F1.3 0 lux (IR light on) |
|||
| Illumination Distance | 150 m (492.13 ft) | |||
| Illuminator On/Off Control | Zoom Prio; Manual; Smart IR; Off | |||
| Illuminator Number | 4 (IR) | |||
| Lens | ||||
| Focal Length | 4.5 mm–144 mm | |||
| Max. Aperture | F1.5–F4.0 | |||
| Field of View | H: 58.4°–3.0°; V: 33.4°–1.7°; D: 66.4°–3.4° | |||
| Optical Zoom | 32× | |||
| Focus Control | Auto; semi-auto; manual | |||
| Close Focus Distance | 0.1 m–1.5 m (0.33 ft–4.92 ft) | |||
| Iris Control | Auto; manual | |||
|
DORI Distance
|
Detect | Observe | Recognize | Identify |
| 1986 m (6515.75 ft) | 785 m (2575.46 ft) | 398 m (1305.77 ft) |
198 m (649.61 ft) |
|
| PTZ | ||||
| Pan/Tilt Range | Pan: 0° to 360° endless Tilt: –15° to +90°, auto flip 180° |
|||
| Manual Control Speed | Pan: 0.1°/s–300°/s Tilt: 0.1°/s–200°/s |
|||
| Preset Speed | Pan: 400°/s; Tilt: 300°/s | |||
| Preset | 300 | |||
| Tour | 8 (up to 32 presets per tour) | |||
| Pattern | 5 | |||
| Scan | 5 | |||
| Power-off Memory | Yes | |||
| Idle Motion | Pattern; Preset; Scan; Tour | |||
| PTZ Protocol | DH-SD Pelco-P/D(Auto recognition) |
|||
| Intelligence | ||||
| IVS (Perimeter Protection) | Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linkage tracking | |||
| Face Detection | Supports face detection, optimization, tracking, capturing pictures, uploading high-quality face snapshots, and face enhancement; Supports attributes extraction. 6 attributes and 8 expressions: Gender, age, glasses, expressions (angry, sad, hate, scary, surprise, calm, happy and confused), mask, mustache; Supports face cutout: Face, one-inch photo. Capturing strategies include real-time capturing, optimization, and quality first. | |||
| Auto Tracking | Yes | |||
| SMD | Yes | |||
| Quick Pick | Yes | |||
| Video | ||||
| Video Compression | H.264H; H.264B;Smart H.265+; H.264; H.265; MJPEG(Sub Stream 1); Smart H.264+ | |||
| Streaming Capability | 3 streams | |||
| Resolution | 1080p (1920 × 1080); 960p (1280 × 960); 720p (1280 × 720); D1 (704 × 576); VGA (640 × 480); CIF (352 × 288) | |||
| Video Frame Rate | Main stream: 1080p/1.3M/720p@ (1–25/30 fps) Sub stream 1: D1/VGA/CIF@ (1–25/30 fps) Sub stream 2: 720p@ (1–25/30 fps) |
|||
| Bit Rate Control | CBR/VBR | |||
| Video Bit Rate | H264: 64 kbps–10496 kbps H265: 25 kbps–6400 kpbs |
|||
| Day/Night | Auto (ICR)/Color/B/W | |||
| BLC | Yes | |||
| WDR | 120 dB | |||
| HLC | Yes | |||
| White Balance | Auto; indoor; outdoor; ATW; manual; sodium lamp; natural light; street lamp | |||
| Gain Control | Auto; manual | |||
| Noise Reduction | 2D NR; 3D NR | |||
| Motion Detection | Yes | |||
| Region of Interest (RoI) | Yes | |||
| Image Stabilization | Electronic (EIS) | |||
| Defog | Electronic | |||
| Digital Zoom | 16× | |||
| Image Rotation | 180° | |||
| Privacy Masking | Up to 24 areas can be set, with up to 8 areas in the same view | |||
| S/N Ratio | ≥ 55 dB | |||
| Audio | ||||
| Audio Compression | PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 | |||
| Network | ||||
| Network Port | 1 × RJ-45 (10/100 Base-T) | |||
| Network Protocol | FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; HTTP; SSL; DHCP; SMTP; Qos; RTSP; ARP | |||
| Interoperability | CGI; SDK; ONVIF (Profile S&G&T); P2P | |||
| Streaming Method | Unicast/Multicast | |||
| User/Host | 20 (total bandwidth: 64 M) | |||
| Storage | Micro SD card (Up to 512 GB); FTP; NAS | |||
| Browser | IE 9 and later versions Chrome 41 and later versions Firefox 50 and later versions iOS 10 and later versions |
|||
| Management Software | DSS; DMSS | |||
| Mobile Client | iOS; Android | |||
| Certification | ||||
| Certifications | CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB, ANSI C63.4-2014 UL: UL60950-1+CAN/CSA C22.2, No.60950-1 |
|||
| Port | ||||
| Audio Input | 1 channel | |||
| Audio Output | 1 channel | |||
| Alarm Linkage | Capture; recording; send email; preset; tour; pattern; alarm digital output | |||
| Alarm Event | Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection | |||
| Alarm I/O | 2/1 | |||
| Audio I/O | 1/1 | |||
| Power | ||||
| Power Supply | 24 VDC, 2.5 A ± 25% PoE+ (802.3at) |
|||
| Power Consumption | Basic: 10 W Max: 22 W (illuminator on) |
|||
| Environment | ||||
| Operating Temperature | –40°C to +70°C | |||
| Operating Humidity | ≤ 95% (RH) | |||
| Protection | IP67; IK10; TVS 6000V lightning proof; surge protection; voltage transient protection | |||
| Structure | ||||
| Product Dimensions | 332 mm × Φ190 mm (13.07″ × Φ7.48″) | |||
| Net Weight | 4.7 kg (10.36 lb) | |||
| Gross Weight | 8.0 kg (17.64 lb) | |||
