Descripción
| Camera | ||||
| Image Sensor | 1/2.8″ CMOS | |||
| Pixel | 2 MP | |||
| Max. Resolution | 1920 (H) × 1080 (V) | |||
| ROM | 128 MB | |||
| RAM | 256 MB | |||
| Electronic Shutter Speed | 1/1 s–1/30,000 s | |||
| Scanning System | Progressive | |||
| Min. Illumination | Color: 0.005 lux@F1.6 B/W: 0.0005 lux@F1.6 0 lux (IR light on) |
|||
| Illumination Distance | 100 m (328.08 ft) (IR) | |||
| Illuminator On/Off Control | Zoom Prio; Manual; Smart IR | |||
| Illuminator Number | 3 (IR) | |||
| Lens | ||||
| Focal Length | 5.0 mm–80.0 mm | |||
| Max. Aperture | F1.6 | |||
| Field of View | H: 53.9°–4.6°; V: 30.3°–2.6°; D: 60°–5.3° | |||
| Optical Zoom | 16× | |||
| Focus Control | Auto; semi-auto; manual | |||
| Close Focus Distance | 0.1 m–2 m (0.33 ft–6.56 ft) | |||
| Iris Control | Fixed | |||
|
DORI Distance
|
Detect | Observe | Recognize | Identify |
| 1,131 m (3,710.63 ft) | 452 m (1,482.94 ft) | 226 m (741.47 ft) | 113 m (370.73 ft) | |
| PTZ | ||||
| Pan/Tilt Range | Pan: 0° to 360° endless Tilt: –15° to +90°, auto flip 180° |
|||
| Manual Control Speed | Pan: 0.1°/s–80°/s Tilt: 0.1°/s–80°/s |
|||
| Preset Speed | Pan: 80°/s; Tilt: 80°/s | |||
| Preset | 300 | |||
| Tour | 8 (up to 32 presets per tour) | |||
| Pattern | 5 | |||
| Scan | 5 | |||
| Power-off Memory | Yes | |||
| Idle Motion | Pattern; Preset; Tour | |||
| PTZ Protocol | DH-SD Pelco-P/D (auto recognition) |
|||
| Intelligence | ||||
| IVS (Perimeter Protection) | Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification | |||
| Face Detection | Support face detection; capturing pictures; face enhancement | |||
| SMD | YES | |||
| Video | ||||
| Video Compression | H.264H; H.264B; Smart H.265+; H.265; MJPEG (Sub Stream 1); Smart H.264+; H.264M | |||
| Streaming Capability | 3 streams | |||
| Resolution | 1080p (1920 × 1080); 960p (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) | |||
| Video Frame Rate | Main stream: 1080p/960p/720p (1–25/30 fps) Sub stream 1: D1/VGA/CIF (1–25/30 fps) Sub stream 2: 1080p/960p/720p (1–25/30 fps) |
|||
| Bit Rate Control | CBR; VBR | |||
| Video Bit Rate | H.264: 1792 kbps–8192 kbps H.265: 512 kbps–5632 kbps |
|||
| Day/Night | Auto (ICR); Color; B/W | |||
| BLC | Yes | |||
| WDR | 120 dB | |||
| HLC | Yes | |||
| White Balance | Auto; indoor; outdoor; ATW; manual; sodium lamp; natural light; street lamp | |||
| Gain Control | Auto; manual | |||
| Noise Reduction | 2D NR; 3D NR | |||
| Motion Detection | Yes | |||
| Region of Interest (RoI) | Yes | |||
| Image Stabilization | Electronic (EIS) | |||
| Defog | Electronic | |||
| Digital Zoom | 16× | |||
| Image Rotation | 180° | |||
| Privacy Masking | Up to 24 areas can be set, with up to 8 areas in the same view | |||
| S/N Ratio | ≥55 dB | |||
| Audio | ||||
| Audio Compression | G.711a; G.711Mu; G.722.1; G.726; MPEG2-Layer2; G.729 | |||
| Network | ||||
| Network Port | RJ-45 (10/100 Base-T) | |||
| Network Protocol | TCP; FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; IP Filter; SMB; HTTP; SSL; DHCP; SMTP; SNMP v1/v2c/v3 (MIB-2); QoS; RTSP; ARP | |||
| Interoperability | CGI; Dahua SDK; API; SDK; ONVIF (Profile S&G&T) | |||
| Streaming Method | Unicast; Multicast | |||
| User/Host | 20 (total bandwidth: 64 M) | |||
| Storage | FTP; Micro SD card (512 GB); NAS | |||
| Browser | IE 7 and later versions Chrome Firefox Safari |
|||
| Management Software | DSS; DMSS; ConfigTool; NVR; Smart PSS; IVSS | |||
| Mobile Client | iPhone; iPad; iOS; Android | |||
| Certification | ||||
| Certifications | CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB, ANSI C63.4-2014 |
|||
| Port | ||||
| Audio Input | 1 channel (LINE IN, bare wire) | |||
| Audio Output | 1 channel (LINE OUT, bare wire) | |||
| Alarm I/O | 2/1 | |||
| Audio I/O | 1/1 | |||
| Alarm Linkage | Capture; preset; tour; pattern; recording; alarm digital input; audio; send email | |||
| Alarm Event | Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection; power exception detection | |||
| Power | ||||
| Power Supply | 12 VDC, 3 A (± 10%) PoE (802.3at) |
|||
| Power Consumption | Basic: 12 W Max.: 20 W (IR light) |
|||
| Environment | ||||
| Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F) | |||
| Operating Humidity | ≤95% | |||
| Protection | IP66; TVS 6000 V lightning proof; surge protection; voltage transient protection | |||
| Structure | ||||
| Product Dimensions | 270.4 mm × Φ160.0 mm (10.65″ × Φ6.30″) | |||
| Net Weight | 2.4 kg (5.29 lb) | |||
| Gross Weight | 3.9 kg (8.60 lb) | |||
