Dahua
DH-IPC-HFW5241E-ZE

Cámara IP Bullet Varifocal 2MP con Wizmind

Consulte disponibilidad en la sucursal más cercana

Dahua

Cámara IP Bullet Varifocal 2MP con Wizmind

Modelo: DH-IPC-HFW5241E-ZE

Cámara de red WizMind Bullet IR Vari-focal de 2MP

  • Sensor CMOS STARVIS™ progresivo de escaneo de 2 megapíxeles de 1/2,8″
  • ROI, SMART H.264+/H.265+, codificación flexible, aplicable a diversos entornos de ancho de banda y almacenamiento
  • 25/30 fps@1080P (1920 × 1080)
  • WDR (120 dB), Día/Noche (ICR), 3D DNR, AWB, AGC, BLC
  • Monitoreo de red múltiple: visor web, CMS (DSS/PSS) y DMSS
  • Lente motorizada de 2,7 mm a 13,5 mm
  • 2/1 Entrada/salida de alarma, 1/1 Entrada/salida de audio
  • Longitud máxima de los LED IR de 50 m
  • Memoria Micro SD, IP67, IK10
Ficha Técnica

Disfruta los precios de la Oferta Flash hasta:

Días
Horas
Minutos
Segundos

$256340

Precio (IVA Incluído)

El precio puede estar sujeto a cambios,
confirme con nuestros asesores de ventas.

Consulte disponibilidad en la sucursal más cercana

Descripción Corta

Cámara de red WizMind Bullet IR Vari-focal de 2MP

  • Sensor CMOS STARVIS™ progresivo de escaneo de 2 megapíxeles de 1/2,8″
  • ROI, SMART H.264+/H.265+, codificación flexible, aplicable a diversos entornos de ancho de banda y almacenamiento
  • 25/30 fps@1080P (1920 × 1080)
  • WDR (120 dB), Día/Noche (ICR), 3D DNR, AWB, AGC, BLC
  • Monitoreo de red múltiple: visor web, CMS (DSS/PSS) y DMSS
  • Lente motorizada de 2,7 mm a 13,5 mm
  • 2/1 Entrada/salida de alarma, 1/1 Entrada/salida de audio
  • Longitud máxima de los LED IR de 50 m
  • Memoria Micro SD, IP67, IK10
Ficha Técnica (en inglés)

Características

Camera
Image Sensor 1/2.8″ CMOS
Max. Resolution 1920 (H) × 1080 (V)
ROM 128 MB
RAM 512 MB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
Min. Illumination 0.002 lux@F1.5 (Color, 30 IRE)
0.0002 lux@F1.5 (B/W, 30 IRE)
0 lux (Illuminator on)
S/N Ratio >56 dB
Illumination Distance 60 m (196.85 ft) (IR)
Illuminator On/Off Control Auto
Illuminator Number 4 (IR LED)
Pan/Tilt/Rotation Range Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens Type Motorized vari-focal
Lens Mount φ14
Focal Length 2.7 mm–13.5 mm
Max. Aperture F1.5
Field of View Horizontal: 109°–30°
Vertical: 57°–17°
Diagonal: 131°–35°
Iris Control Auto
Close Focus Distance 0.8 m (2.62 ft)
DORI Distance Lens Detect Observe Recognize Identify
W 44.1 m (144.69 ft) 17.6 m (57.74 ft) 8.8 m

(28.87 ft)

 4.4 m

(14.44 ft)
T 146.2 m (479.66 ft) 58.4 m (191.60 ft) 29.2 m (85.80 ft) 14.6 m (47.90 ft)
Smart Event
IVS Abandoned object; missing object
Heat Map Yes
Professional, intelligent
IVS (Perimeter Protection) Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection
SMD 3.0 Less false alarm, longer detection distance
Face Detection Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes (gender, age, glasses, expressions, mask, and beard) and 8 expressions (angry, sad, disgusted, scared, surprised, calm, happy, confused); face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting
People Counting Tripwire people counting and people counting in area; generating and exporting report (day/month/year); queue management; 4 rules can be set for tripwire, people counting in area and queue management
Smart Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
Video
Video Compression H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec Smart H.265+; Smart H.264+
AI Coding AI H.265; AI H.264
Video Frame Rate Main stream: 1920 × 1080@(1 fps–25/30 fps)
Sub stream: D1@(1 fps–25/30 fps)
Third stream: 1080p@(1 fps–25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Stream Capability 3 streams
Resolution 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control CBR/VBR
Video Bit Rate H.264: 32 kbps–8192 kbps
H.265: 32 kbps–8192 kbps
Day/Night Auto(ICR)/Color/B/W
BLC Yes
HLC Yes
WDR 120 dB
Scene Self-adaptation (SSA) Yes
White Balance Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control Auto;Manual
Noise Reduction 3D NR
Motion Detection OFF/ON (4 areas, rectangular)
Region of Interest (RoI) Yes (4 areas)
Image Stabilization Electronic Image Stabilization (EIS)
Smart Illumination Yes
Defog Yes
Image Rotation 0°/90°/180°/270°
Mirror Yes
Privacy Masking 8 areas
Audio
Audio Compression PCM; G.711a; G.711Mu; G.726; G.723
Alarm
Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; defocus detection; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; input error; voltage detection; face detection; people counting in area; stay detection; people counting; people number error detection; queue management; intensity change
Network
Network Port RJ-45 (10/100 Enhancement Base-T)
SDK and API Yes
Cyber Security Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Network Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; Bonjour
Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone
User/Host 20 (Total bandwidth: 88 M)
Storage FTP; SFTP; Micro SD card (support max. 256 GB); NAS
Browser IE: IE8 and later
Chrome
Firefox
Management Software Smart PSS, DSS, DMSS
Mobile Client iOS; Android
Certification
Certifications CE-LVD: EN 62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
Port
Audio Input 1 channel (RCA port)
Audio Output 1 channel (RCA port)
Alarm Input 2 channels in: 5 mA 3–5 VDC
Alarm Output 1 channel out: 300 mA 12 VDC
Power
Power Supply 12 VDC (±30%); PoE (802.3af); ePoE
Power Consumption Basic: 2.5 W (12 VDC); 3.2 W (PoE)
Max. (max. stream + IR LED + focus): 9.4 W (12 VDC); 10.3 W (PoE)
Environment
Operating Temperature –30 °C to +60 °C (–22 °F to +140 °F)
Operating Humidity ≤95%
Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F)
Protection IP67; IK10
Structure
Casing Metal + plastic
Product Dimensions 273.2 mm × 95 mm × 95 mm (10.76″ × 3.74″ × 3.74″) (L × W × H)
Net Weight 1110 g (2.45 lb)
Gross Weight 1510 g (3.33 lb)
